ZC-OPS1030 OPS PC With Nvidia GT1030

ZC-OPS1030 OPS Mini PC With Intel LGA1151 Socket,Graphics Card Nvidia GT1030

Support 7th Gen I3/I5/I7 CPU,With DP,HDMI,Support Double Display,4*USB 3.0,

2*USB 2.0,1*MIC,1*SPK,1*RJ45 Lan Port,1*OPS Port,2*WIFI Antenna Ports,

19V DC In

Main Features:

1. With Intel LGA 1151 Socket,Support 6th,7th Gen Core I3/I5/I7.

2. Onboard Graphics Card Nvidia GT1030,Support 4K.

2. Standard OPS Frame,the Size is 195*180*42.5mm.

3. Double Display,With DP and HDMI,Support Double Display.

4. With MINI SATA ,SATA,M.2 Slots,Support Both SSD and 2.5 inch HDD.

5. Onboard MINI PCIE ,Support WIF.SIM Card Can Be Customized.

6. Silent Fan,Low Noise,Excellent Heat Exchange.

7. Good Quality:All Solid Cap,With Stable and Reliable Performance.

ZC-OPS1030 OPS Mini PC Specification

CPU	With Intel LGA 1151 Socket Support LGA 1151 Core i3/i5/i7/Pentium/Celeron 6th Generation and 7th Generation
Chipset	Intel H110
RAM	2*SO-DIMM DDR4 2133/2400M,Max 32GB
Graphics	Onboard Nvidia GT1030,2GB DDR5 Memory HDMI 1.4B: Max 40962160@30Hz DP 1.2:Max 40962160@60Hz OPS JAE:Max 4096*2160@60Hz
Hard Disk	1SATA 2.5inch 500GB,1TB,2TB 1mSATA SSD 32GB,64GB,128GB,256GB 1*M.2 SSD 32GB,64GB,128GB,256GB
Network Card	1*RTL8111F Gigabit Card WIFI Optional
OUT I/O Port	1DC Port 1HDMI 1.4B 1DP 1.2 4USB 3.0 2USB 2.0 1RJ45 1MIC 1Audio Out 2WIFI Antenna Ports 1Power Button 1OPS JAE TX25 Port 1RS232 Optional
Size	19518042.5mm
Weight	N.W.:1.8KG
Power Adapter	Φ=5.5*2.5mm DC Port,DC 19V. It is optional,Need Additional Cost
