ZC-OPS110 Socket LGA1151 OPS PC Module Support Core i3/i5/i7
- Description
ZC-OPS110 Mini PC With Intel LGA1151 Socket,Support 7th Gen I3/I5/I7 CPU
With VGA,HDMI,Support Double Display,4*USB 3.0,2*USB 2.0,1*MIC,1*SPK
1*RJ45 Lan Port,1*OPS Port,2*WIFI Antenna Ports,12V/19V DC IN
Main Features:
1. With Intel LGA 1151 Socket,Support 6th,7th I3/I5/I7 CPU.
2. Standard OPS Frame,the Size is 195*180*42.5mm.
3. Double Display:With VGA and HDMI,Support Double Display.
4. With MINI SATA and SATA,Support Both SSD and 2.5 inch HDD.
5. Onboard MINI PCIE ,Support WIF.SIM Card Can Be Customized.
6. Silent Fan,Low Noise,Excellent Heat Exchange.
7. Good Quality:All Solid Cap,With Stable and Reliable Performance.
ZC-OPS110 OPS Mini PC Specification
|
CPU |
With Intel LGA 1151 Socket Support LGA 1151 i3/i5/i7 CPU 6th generation and 7th generation |
|
Chipset |
Intel H110 |
|
RAM |
1*SO-DIMM DDR4 |
|
Hard Disk |
SATA 2.5inch 500GB,1TB mSATA SSD 32GB,64GB,128GB,256GB |
|
Network Card |
1*Intel I218LM Gigabit Card WIFI Optional |
|
OUT I/O Port |
1*DC Port 1*HDMI 1*VGA 4*USB 3.0 2*USB 2.0 1*RJ45 1*MIC 1*SPK 2*WIFI Antenna Port 1*Power Button 1*OPS Port 1*RS232 Optional |
|
Size |
195*180*42.5mm |
|
Weight |
N.W.:1.8KG |
|
Power Adapter |
Input:100-240V(AC) Output:12V/19V(DC) It is optional,Need Additional Cost |
