ZC-OPS7200 OPS PC With Core i5-7200u Support 4K
- Description
ZC-OPS7200 OPS Mini PC With 7th Gen Kaby lake I5-7200u Dual Core 4 Thread 2.5GHz
Turbo Boost 3.1GHz,Intel HD 620 GPU,Support 4K,3*USB 3.0,1*USB 2.0
1*RJ45 Lan Port,1*OPS,1*VGA,DC12V-19V.
Main Features:
1.Onboard CPU INTEL I5-7200u Dual Core 4 Thread 2.5GHz.
Turbo Boost 3.1GHz,3MB L3 Cache TDP only 15W.
2.Standard OPS Frame,the Size is 200*119*30mm.
3.With Graphic Card:Intel HD520,Support 4K.
4.With MINI SATA and SATA,Support Both SSD and 2.5 inch HDD.
5.Onboard MINI PCIE and SIM Card Slot,Support WIFI/3G/4G Module.
6.Silent Fan,Low Noise,Excellent Heat Exchange.
7.Good Quality:All Solid Cap,With Stable and Reliable Performance.
ZC-OPS7200 OPS Mini PC Specification
|
CPU |
7th Gen INTEL Kaby Lake I5-7200u Dual Core 4 Thread 2.5GHz Turbo Boost 3.1GHz 3MB L3 Cache TDP only 15W |
|
RAM |
2*SO-DIMM DDR3L(1.35V) 1600MHz Memory Max 16GB |
|
Hard Drive Capacity |
SATA 2.5 500GB,1TB or mSATA SSD 16GB,32GB,64GB,128GB,256GB |
|
Graphics Card |
Intel HD 620 Support 4K |
|
Network Card |
1*Intel I219 Gigabit Network Card WIFI Optional |
|
Outside I/O Ports |
1*DC Port 1*VGA 1*OPS 3*USB 3.0 1*USB 2.0 1*RJ45 1*COM 1*Power Button 2*WIFI Antenna Ports |
|
Internal I/O Port |
1*SATA 3.0 1*MINI SATA 3.0,Support SSD 1*MINI PCIE(Support WIFI or 3G/4G Module) |
|
Size |
Product Size:200*119*30mm |
|
Power Adapter |
Input 100-240V(AC) Output:12V-19V DC-IN It is optional,Need Additional Cost |
