ZC-OPS470 I3-3217u OPS PC Module

ZC-OPS470 OPS Mini PC With INTEL Ivy Bridge I3-3217U CPU Dual Core 1.80 GHz

Intel HD 4000 GPU,Support 1080P Playing.With VGA,HDMI,Support Double Display

2*USB 3.0,1*MIC,1*SPK,1*RJ45 Lan Port,1*2.5inch HDD Push-Pull

2*WIFI Antenna Port,1*OPS Port

Main Features:

1.Onboard CPU INTEL Ivy Bridge I3-3217U Dual Core 4 Thread 1.80GHz,

3MB L3 Cache TDP only 17W

2.Standard OPS Frame,the Size is 20*11.9*3CM.

3.With Graphic Card:Intel HD4000,Support 1080P Playing.

4.Double Display:With VGA and HDMI,Support Double Display.

5.With MINI SATA and SATA,Support Both SSD and 2.5 inch HDD,Great Storage.

6.Onboard MINI PCIE and SIM Card Slot,Support WIFI and 3G Module.

7.Can Built-in IR Module,Support IR Remote Control.

8.Silent Fan,Low Noise,Excellent Heat Exchange.

9.Good Quality:All Solid Cap,With Stable and Reliable Performance.

10.Built-in SATA Port, With 2.5inch HDD Push-Pull Ports,Very Convenient.

ZC-OPS470 Mini PC Specification

CPU	Onboard Intel Ivy Bridge I3-3217U Dual Core 4 Thread 1.80GHz 3MB L3 Cache TDP only 17W
RAM	1*DDR3 SO-DIMM 1600MHz Memory,Max 8GB
Hard Drive Capacity	SATA 2.5 inch250GB,320GB, 500GB,1TB or mSATA SSD 8GB ,16GB,32GB,64GB Optional
Graphics Card	Intel HD 4000,650-1250MHz, Support 1080P
Chipset	Intel HM77
Network Card	Intel 82579 Network Card WIFI Optional
Storage	1MINI SATA SSD 2SATA 2.5 inch HDD
OUT I/O Port	1DC Port 1HDMI 1VGA 2USB 3.0 1IR 1RJ45 1MIC 1SPK 1Power Button 1Reset Button 1HDD LED 1Power LED 1OPS Port 2WIFI Antenna Port 1*2.5inch HDD Push-Pull
Internal I/O Port	112PINS VGA 1RS232 PINS 1IR Module Slot 1SIM Card Slot 1SO-DIMM Memory Slot 1MINI SATA,Support SSD 1*MINI PCIE
Size	Product Size:20011930mm
Power Adapter	Input 100-240V(AC), Output:12V/19V DC-IN Power Adapter Optional,Need Additional Cost
