CPU

Intel Gemini Lake J4125

4 Cores 2.00GHz Burst to 2.7GHz.

4MB Cache,TDP 10W

Chipset

Soc

Display

Onboard Intel® UHD Graphics 600,Support DirectX 12 OpenGL 4.4,Max 4096X2304

1*HDMI1.4,Max 4096X2304@30Hz

1*VGA,Max 1920X1080

1*LVDS Dual Channel 24Bit,2*eDP Connector

Network Card

1*Intel I225 2.5GbE(Default)

2*Intel I225 2.5GbE(Optional)

Support Wake On LAN,PXE

LAN 1 Support POE-PD,Powered Device(Optional)

Memory

1*SO-DIMM DDR4

Storage

1*SATA3.0

1*M.2(Key M) SATA/NVME(Choose by Jumper)

Expansion

1*M.2(Key E) for WIFI

1*M.2(Key B) for 3G/4G

Rear I/O

2*USB3.0,2*USB 2.0

1*HDMI

1*VGA

1*Line Out,1*MIC

1*RJ-45

1*DC-IN 12V 5A( Ф2.5mm)

Inside I/O

1*LVDS Dual Channel 24Bit,2*15Pins

1*LVDS backlight power supply Header,1*6Pins

2*eDP

2*USB 2.0,2*5Pins(F_USB3)

2*USB 2.0,2*5Pins(F_USB4)

1*Front Audio,2*5Pins

1*Front Panle for Power/LED,2*5Pins

1*SATA Power 1*4pin

1*Amplifier Header 1*4pin

1*GPIO support 16 Input output

1*4Pin SATA Power

1*SIM Slot

1*4pin ATX

6*COM,COM2/COM3 Support RS485/422/232(6*COM Optional)

2*COM(Default)

Power Supply

DC 12V

Cooling System

Fanless Passive Cooling

Working Temp

-10℃～60℃

Storage Temp

-20℃～70℃

Working humidity

5%-95% Relative humidity, non-condensing

Size

170mm x 170mm
