CPU

Intel Ivy Bridge 1037U CPU

Dual Core 1.80 GHz

2MB L2 Cache,22nm

TDP 17W

RAM

1*SO-DIMM DDR3 1600MHz Memory,MAX 8GB

Chipset

Intel NM70

Graphics Card

NVDIA GT730,2GB Video Memory

Support 4K Playing

SATA

2*SATA Slots

Audio card

Realtek ALC662

Network Card

1*Realtek 8111E

10/100/1000M Network Card

Amplifier

Built-in SPK Ports,Support 2W,3W,5W Speaker

Display

1*HDMI

1*VGA

1*LVDS

LVDS

1*Double Channel 24Bit LVDS

Expansion Slot

1*MINI PCI-E Support SSD

1*MINI PCI-E Support WIFI,3G

Support Both Full Size and Half Size

1*SIM Card Slot

 Rear Panel I/O

4*USB 2.0

1*RJ-45

1*HDMI

1*VGA

1*DC12V_JACK

1*AUDIO Line Out

1*MIC IN

 Internal I/O

1*F-AUDIO1

1*SPDF

1*AUTO Power ON Switch

1*F-USB(Support 2 USB Ports)

1*F-USB1(Support 2 USB Ports)

2*COM PINS

1*GPIO-CON

1*CN1

F-PANEL1

2*SATA Slots

2*SATA Power Slots

1*SYS-FAN1 PWR

1*CPU FAN PWR

1*ATX1 4PINS

1*30PINS LVDS

1*VGA PINS

1*LVDS 3.3V/5V/12V Jump Hat

Power Supply

12V DC-In

4PIN DC-ATX

Size

MINI ITX(17*17)
